| Detailed Specifications |
| CAMERA |
|
| Type |
Compact digital still camera with built-in flash, 3x Optical/4x Digital/12x Combined Zoom with Optical Image Stabilizer System |
| IMAGE CAPTURE DEVICE |
|
| Type |
12.1 Megapixel, 1/2.3-inch type Charge Coupled Device (CCD) |
| Total Pixels |
Approx. 12.7 Megapixels |
| Effective Pixels |
Approx. 12.1 Megapixels |
| LENS |
|
| Focal Length |
6.2-18.6mm f/2.8-4.9 (35mm film equivalent: 35-105mm) |
| Digital Zoom |
4x |
| Focusing Range |
Normal: 1.0 ft./30cm-infinity
Macro: 1.2 in.-1.6 ft./3-50cm (W), 1.0-1.6 ft./30-50cm (T) |
| Autofocus Range |
TTL Autofocus |
| VIEWFINDER & MONITOR |
|
| Viewfinder |
N/A |
| LCD Monitor |
2.5-inch TFT color LCD with wide viewing angle (PureColor LCD II) |
| LCD Pixels |
Approx. 230,000 pixels |
| LCD Coverage |
100% |
| APERTURE & SHUTTER |
|
| Maximum Aperture |
f/2.8 (W) - f/4.9 (T) |
| Shutter Speed |
15-1/1500 sec.; Long Shutter operates with noise reduction when manually set at 1.3-15 sec. |
| EXPOSURE CONTROL |
|
| ISO Sensitivity |
Auto, ISO 80/100/200/400/800/1600 equivalent (Standard output sensitivity. Recommended exposure index) |
| Light Metering Method |
Evaluative*, Center-weighted average, Spot**
* Control to incorporate facial brightness in Face Detection AF
** Metering frame is fixed to the center |
| Exposure Control Method |
Program AE, i-Contrast; AE Lock |
| Exposure Compensation |
+/-2 stops in 1/3-stop increments |
| WHITE BALANCE |
|
| White Balance Control |
Auto, Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Underwater, Custom |
| FLASH |
|
| Built-in Flash |
Auto, Red-eye Reduction, Auto Red-eye Correction, Flash On, Flash Off; FE lock, Slow Synchro |
| Flash Range |
1.0-10 ft./30cm-3.2m (W), 1.0-6.6 ft./30cm-2.0m (T) (when sensitivity is set to ISO Auto) |
| Recycling Time |
10 sec. or less (battery voltage=3.7V) |
| Flash Exposure Compensation |
N/A |
| SHOOTING SPECIFICATIONS |
|
| Shooting Modes |
Auto, P, Special Scene (Portrait, Landscape, Night Scene, Foliage, Snow, Beach, Sunset, Fireworks, Aquarium, Underwater, ISO 3200, Long Shutter, Indoor, Kids & Pets, Night Snapshot, Color Accent, Color Swap, Stitch Assist), Movie |
| Photo Effects |
My Colors
Vivid, Vivid Blue, Vivid Green, Vivid Red, Neutral, Sepia, Black & White, Positive Film, Lighter Skin Tone, Darker Skin Tone, Custom |
| Self Timer |
Activates shutter after an approx. 2-sec./10-sec. delay, Face Detection Self-timer |
| Wireless Control |
N/A |
| Continuous Shooting |
Approx. 1.1 fps (Large/Fine) |
| IMAGE STORAGE |
|
| Storage Media |
SD/SDHC Memory Card, MultiMediaCard, MMC Plus Card, HC MMC Plus Card |
| File Format |
Design rule for camera file system, DPOF Version 1.1 |
| Image Compression |
Normal, Fine |
| JPEG Compression Mode |
Still Image: Exif 2.2 (JPEG)
Movie: MOV (Image: H.264; Audio: Linear PCM (Monaural)) |
| Number of Recording Pixels |
Still Image: 4000 x 3000 (Large), 3264 x 2448 (Medium 1), 2592 x 1944 (Medium 2), 1600 x 1200 (Medium 3/Date Stamp), 640 x 480 (Small), 4000 x 2248 (Widescreen)
Movie: Standard Definition: 640 x 480 (30 fps), 320 x 240 (30 fps)
Available up to 4GB or 60 minutes per clip |
| Number of Recordable Images |
| |
Large (L) |
Medium 1 (M1) |
Medium 2 (M2) |
Medium 3 (M3) |
| F |
N |
F |
N |
F |
N |
F |
N |
| File Size (KB) |
3,084 |
1,474 |
2,060 |
980 |
1,395 |
695 |
558 |
278 |
| 2GB |
626 |
1,280 |
930 |
1,920 |
1,365 |
2,672 |
3,235 |
6,146 |
| 8GB |
2,505 |
5,116 |
3,721 |
7,675 |
5,457 |
10,679 |
12,927 |
24,562 |
| |
Small (S) |
Widescreen (W) |
| F |
N |
F |
N |
| File Size (KB) |
150 |
84 |
2,311 |
1,105 |
| 2GB |
10,245 |
15,368 |
830 |
1,707 |
| 8GB |
40,937 |
61,406 |
3,318 |
6,822 |
|
| Time of Recordable Movies |
| |
Standard, Color Accent, Color Swap |
| 640 x 480 |
320 x 240 |
| 30 fps |
30 fps |
| Movie size (KB/sec.) |
1,316 |
394 |
| 2GB |
23 min. 49 sec. |
1 hr. 13 min. 10 sec. |
| 8GB |
1 hr. 35 min. 11 sec. |
4 hr. 52 min. 24 sec. |
Note: N=Normal F=Fine
Storage Capacity varies depending on camera settings. This data is estimated from Canon's standard shooting conditions. Figures for Movie Mode represent total capacity of the particular media. |
| PLAYBACK & ERASE |
|
| Playback Modes File |
Still Image: Single, Magnification (approx. 2x-10x), Jump, Auto Rotate, Rotate, Resume, My Colors, My Category, Transition Effects, Histogram, Index (9 thumbnails), Slide Show, Over Exposure Warning, Slide Show, Red-eye Correction, Trimming, Resize, Image Inspection Tool, i-Contrast;
Movie: Normal Playback, Special Playback, Auto Rotate, Resume |
| Erase Modes |
Still Image: single image, select range, select by date, select by category, select by folder, all images
Movie: any movie files |
| INTERFACES |
|
| Computer Interface |
USB 2.0 Hi-Speed (mini-B jack) |
| Video Out |
NTSC/PAL |
| Audio Out |
Monaural |
| Other |
Memory card slot; direct connection to Canon SELPHY Compact Photo Printers, PIXMA Photo Printers and PictBridge-compatible printers via camera's USB 2.0 Hi-Speed cable |
| POWER SUPPLY |
|
| Power Source |
1. Rechargeable Lithium-ion Battery NB-6L
2. AC Adapter Kit ACK-DC40 (optional) |
| Shooting Capacity |
Still Image: approx. 220 shots*
* LCD screen on. The above figures comply with CIPA testing standards and apply when fully-charged batteries are used. |
| Playback Time |
Approx. 360 min. |
| PHYSICAL SPECIFICATIONS |
|
| Operating Temperature |
14-104°F/-10-40°C |
| Operating Humidity |
10-90% |
| Dimensions (WxHxD) |
4.08 x 2.63 x 1.92 in./103.6 x 66.9 x 48.8mm |
| Weight |
Approx. 6.70 oz./190g (camera body only) |
| Note |
26 display languages provided (English, German, French, Dutch, Danish, Finnish, Italian, Norwegian, Swedish, Spanish, Simplified/Traditional Chinese, Japanese, Russian, Portuguese, Korean, Greek, Polish, Czech, Hungarian, Turkish, Thai, Arabic, Romanian, Ukrainian, Farsi) |
