| Detailed Specifications |
| Projection System |
Epson 3LCD, 3-chip technology |
| Projection Method |
Front/rear/ceiling mount |
| Driving Method |
Epson Poly-silicon TFT Active Matrix |
| Pixel Number |
1,024,000 dots x 3 (1280 x 800) LCDs |
| White Light Output |
3000 lumens (ISO 21118 standard) |
| Colour Light Output |
3000 lumens |
| Aspect Ratio |
16:10 (supports 4:3 and 16:9) |
| Native Resolution |
1280 x 800 (WXGA) |
| Resize |
640 x 480 (VGA), 800 x 600 (SVGA),
1024 x 768 (XGA), 1280 x 1024 (SXGA),
1400 x 1050 (SXGA+), 1440 x 900 (WXGA+),
1680 x 1050 (WSXGA+), 1600 x 1200 (UXGA) |
| Lamp Type |
230 W UHE |
| Lamp Life |
Up to 4000 hours (ECO Mode)
Up to 4000 hours (Normal Mode) |
| Throw Ratio Range |
1.35 – 1.62 |
| Size (projected distance) |
30" – 300" 16:10 (2.2' – 26.8') |
| Keystone Correction (automatic) |
Vertical: ± 30 degrees (± 45 manual)
Horizontal: ± 20 degrees (± 30 manual) |
| Contrast Ratio |
Up to 2000:1 |
| Colour Reproduction |
16.77 million colours |
| Plug ‘n Play |
Projector is compatible with PC & Mac
computers |
| PROJECTION LENS |
Powered focus/Manual zoom |
| F-number |
1.58 – 1.7 |
| Focal Length |
13.52 – 16.22 mm |
| Zoom Ratio |
Optical zoom 1.0 – 1.2 |
| OTHER |
|
| Display Performance |
NTSC: 480 line
PAL: 576 line
(depends on observation of the
multi-burst pattern) |
| Input Signal |
NTSC / NTSC4.43 / PAL / M-PAL / N-PAL /
PAL60 / SECAM SDTV / HDTV |
| Interfaces |
Computer/component video:
Mini D-sub HD 15 pin x 1
Composite video: RCA x 1
Audio in: Mini stereo x 1 in or out user selectable
Variable audio out: Mini stereo x 1 in or out user
selectable
USB connector: Type B x 1 (USB display with
audio and mouse/keyboard control)
Type A x 1 (for USB memory device)
HDMI
Wireless LAN module: 802.11 b/g/n |
| Audio Output |
1 W mono speaker |
| Audio Signal |
500mV rms/47K ohm |
| Operating Temperature |
41 ° to 95 °F (5 ° to 35 °C) |
| Power Supply Voltage |
100 – 240 V ± 10%, 50/60 Hz AC |
| Power Consumption |
322 W (Normal Mode)
212 W (ECO Mode)
7.4 W Standby (Communication On)
0.38 W Standby (Communication Off) |
| Fan Noise |
40 dB (Normal Mode)
30 dB (ECO Mode) |
| Security |
Kensington®-style lock provision |
| Dimensions (W x D x H) |
Including feet: 11.5" x 8.3" x 2.1"
Excluding feet: 11.5" x 8.3" x 1.7"
Weight: 3.8 lb |
| REMOTE CONTROL |
|
| Features |
Power, source search selection, computer,
video, A/V mute, freeze, user ID, auto,
aspect, colour mode, num, page up and
down, E-zoom, volume, help, menu, enter,
esc and pointer functions |
| Operating Angle |
Right/left:
Front: ± 60 degrees
Rear: ± 30 degrees
Upper/lower:
Front: ± 30 degrees
Rear: ± 30 degrees |
| Operating Distance |
19.7 ft |
