| Detailed Specifications |
| SENSOR |
|
| Type |
1/2.33 inch interline transfer CCD with primary colour filter |
| Effective Pixels |
16 megapixels |
| Total Pixels |
16.56 megapixels |
| Recording Resolutions |
Still: 16M (4608x3456), 12M (1:1, 3456x3456), 12M (16:9, 4608x2592), 7M (3072x2304), 2M (16:9, 1920x1080), VGA (640x480)
Movie: HD (1280x720p30/15), VGA (640x480p30/15),
QVGA (320x240p30/15) |
| Quality Levels |
Fixed |
| LENS |
|
| Type/Construction |
smc PENTAX zoom lens, 11 elements in 8 groups (1 aspheric element) |
| Focal Length (equiv.) |
5-100mm (28-560mm) |
| Aperture |
F3.1-4.8 |
| Optical Zoom |
20X |
| Digital Zoom |
7.2X |
| Combined Zoom |
144X |
| Intelligent Zoom |
Approx 30X at 7M to 144X at VGA |
| LCD |
|
| Type |
3.0-inch TFT colour LCD
Resolution: HVGA (460,000 dots)
Wide Angle Viewable: Yes |
| FLASH |
|
| Type |
Built-in series control auto flash |
| Modes |
Auto, Flash Off, Flash On, Auto + Redeye, On + Redeye |
| Effective Range |
5.1m (wide, auto ISO), 3.3m (tele, auto ISO) |
| FOCUSING SYSTEM |
|
| Type |
TTL contrast detection autofocus |
| Focus Modes |
3 point AF, Spot AF, Auto Tracking AF, Macro, Super Macro, Infinity Landscape, Manual Focus |
| Focus Lock |
Yes, by pressing the shutter release button half way |
| Focus Range |
Normal: 0.4m to infinity (wide), 1.6m to infinity (tele)
Macro: 0.1-0.5m (wide)
Super Macro: Approx 0.01-0.2m (middle zoom position) |
| METERING SYSTEM |
|
| Type |
TTL Multi-segment Metering |
| Exposure Compensation |
±2EV(1/3EV steps) |
| SENSITIVITY |
|
| Auto |
100-1600 (auto range adjustable), Digital SR 100-6400 |
| Manual |
100-6400 |
| WHITE BALANCE |
|
| Modes |
Auto, Daylight, Shade, Tungsten light, Fluorescent light, Manual setting |
| IMAGE STABILIZATION |
|
| Still |
Sensor-Shift SR, Digital SR (ISO 3200-6400 5M) |
| Movie |
Movie SR |
| SHUTTER |
|
| Type |
Programmed AE electronic lens shutter with electronic sensor shutter |
| Shutter Speed |
1/2500 to 1/4 sec (up to 4 sec in Night Scene mode) |
| DRIVE MODES |
|
| Mode Selection |
One Shot, Self Timer, Continuous, Burst 5M (H/L), Multi-Burst (5M, 16 VGA frames), Remote Control, Auto Bracketing |
| Continuous FPS |
Approx. 1 FPS for 6 frames |
| Self-timer |
Yes (10 sec, 2 sec) |
| Remote Control |
Infrared (using optional PENTAX remote Controller) |
| CAPTURE MODES |
|
| Mode Selection |
Auto Picture (Standard, Landscape, Portrait, Night Scene Portrait, Night Scene, Sport, Flower, Candlelight, Blue Sky, Sunset, Text, Group Photo, Pet, Portrait x Blue Sky, Portrait x Sunset, Portrait x Backlight), Program, Natural Skin Tone, Handheld Night Snap (5M), Night Scene Portrait, Night Scene, Digital Panorama (2M per frame), Landscape, Blue Sky, Sunset, Flower, Digital SR (ISO 3200-6400 5M), Kids, Pet, Portrait, Food, Fireworks, Surf & Snow, Sport, Fisheye, Sketch, Miniature Filter, Text, Frame Composite (3M), Movie, Green |
| Face Detection |
Yes (up to 10 faces), Smile Capture, Blink Detection, Face Recall |
| Date Stamp |
Yes, date, date-time, time (not available in Green mode) |
| Dynamic Range Adjustment |
Yes, highlight and shadow correction |
| PLAYBACK MODES |
|
| Mode Selection |
One Shot, Index (4 or 9 thumb nails), Magnification(up to 10X, scrollable), Movie Playback, Histogram, Folder display, Select & Delete, Calendar |
| Mode Palette |
Slideshow, Image Rotation, Stretch Filter, Small Face Filter, Digital Filter, Frame Composite (3M), Movie Edit, Red-eye Edit, Resize, Cropping, Image Copy, Protect, DPOF, Startup Screen |
| Digital Filters (playback) |
B&W, Sepia, Toy Camera, Retro, Colour, Extract Colour, Starburst, Soft, Fisheye, Brightness Filter, Miniature, Natural Skin Tone, Stretch |
| Movie Edit |
Save as still image, movie divide |
| FILE FORMATS |
|
| Still |
JPG (EXIF 2.3), DCF 2.0, DPOF, Print Image Matching III |
| Movie (compression) |
AVI (Motion JPG) |
| STORAGE MEDIA |
|
| Internal Memory |
16MB |
| Removable Memory |
SD, SDHC, SDXC |
| INTERFACES |
|
| Ports |
USB 2.0 hi-speed, AV out |
| Video Out |
NTSC, PAL |
| POWER SUPPLY |
|
| Power Source |
Rechargeable Li-Ion battery D-LI122 |
| Recordable Images |
Approx 200* |
| Playback Time |
Approx 180min** |
| Movie Recording Time |
Approx 100 min** |
| AC Adapter Available |
Yes (optional) |
| LANGUAGE SUPPORT |
|
| Languages |
English, French, German, Spanish, Portuguese, Italian, Dutch, Danish, Swedish, Finnish, Polish, Czech, Hungarian, Turkish, Greek, Russian, Thai, Korean, Traditional Chinese, Simplified Chinese, Japanese |
|
PHYSICAL SPECIFICATIONS
|
|
| Computer System Requirements* |
Windows: Windows XP (SP3), Vista, 7, USB port
Mac: 10.4, 10.5, 10.6, 10.7, USB port
*For device connectivity. Bundled software requirements may vary.
|
| Operating Temperature |
0-40°C |
| Dimensions |
112 x 61.5 x 38.5mm (W x H x D) |
| Weight |
Without battery or removable memory: 213g
Loaded and ready: 234g |
| NOTES |
* Recording capacity above shows approximate number of shots recorded during CIPA-compliant testing. Actual performance may vary depending on operating conditions.
** According to the result of PENTAX in-house testing
|
