| Detailed Specifications |
| Mount Type |
PL |
| Focal Length |
30-300mm |
| Zoom Ratio |
10x |
| Maximum Relative Aperture |
T 1:2.95 at 30-240mm
T 1:3.7 at 300mm |
| Number of Aperture Blades |
11 |
| Angle of View |
For 24.6 x 13.8mm (Canon Super 35 sensor):
43.6 x 25.4° at 30mm
4.6 x 2.6° at 300mm
For 24.0 x 13.5mm (3-perf Super 35mm film frame):
44.6 x 25.9° at 30mm
4.7 x 2.6° at 300mm |
| Minimum Object Distance (M.O.D.) |
5' (1.5 m) |
| Object Dimensions at M.O.D. |
For 24.6 x 13.8mm (Canon Super 35 sensor):
38.9 x 21.9" (98.8 x 55.6 cm) at 30mm
3.8 x 2.1" (9.6 x 5.4 cm) at 300mm
For 24.0 x 13.5mm (3-perf Super 35mm film frame):
39.9 x 22.4" (101.3 x 56.8 cm) at 30mm
3.9 x 2.2" (9.9 x 5.6 cm) at 300mm |
| Front Lens Diameter |
136mm |
| Dimensions (WxHxD) |
5.67 x 6.58 x 13.78" (144.0 x 167.1 x 350.1mm) |
| Weight (Approx.) |
12.79 lb (5.8 kg) |
