• Webcode: 421368 • Mfr: PA243W-BK-SV
Product Highlights
  • 24.1" Widescreen LCD Monitor
  • 1920 x 1200 Resolution
  • In-Plane Switching IPS Technology
  • HDMI / DisplayPort / DVI-D / VGA Inputs
  • 1,000:1 Contrast Ratio
  • 16.7 Million Colours
  • 178° View Angle
  • Includes SpectraView II
NEC PA243W-BK-SV - 24.1" 16:10 IPS, 99.8% Adobe RBG, 95.5% DCI-P3, LCD Monitor with SpectraView II) NEC PA243W-BK-SV - 24.1" 16:10 IPS...
Web Availability: Special Order
Vistek Locations
  • Toronto Special Order
  • Ottawa Special Order
  • Mississauga Special Order
  • Calgary Special Order
  • Edmonton Special Order
Please call and verify availability at the store as stock changes daily.

Lease this for: $63.74 Learn More

Overview

Trusted colour accuracy. The PA243W is a 24” IPS LCD monitor that raises the bar for colour critical applications including photography and video editing. Offering an full 100% coverage of sRGB colour gamut, 99.8% of Adobe RGB, 95.5% of DCI-P3 and 80.0% of Rec 2020, you can trust that the PA243W will deliver the colours that you need. Its always-on backlight sensor, internal 14-bit 3D programmable lookup tables (LUTs) provide stable white points and accurate colour rendition for the life of the display, especially when used with the included SpectraViewII colour calibration software and MDSVSENSOR3 calibration sensor. 10-bit DisplayPort and HDMI connectivity provides the highest colour fidelity and built-in USB 3.1 hub with DisplaySync Pro™ makes it a fit for any configuration. In addition, Picture in Picture and Picture by Picture modes allow for real-time print emulation, simplifying your workflow.

Key Features:

  • SpectraViewII Color Calibration Solution , which includes software and colourimeter, helps the display achieve accurate, consistent and repeatable colour performance
  • IPS LCD panel with wide viewing angles and excellent colour reproduction and superior screen performance
  • Internal programmable 14-bit 3D lookup tables (LUTs) ensure accurate colour rendition
  • 3-port USB 3.1 hub with DisplaySync ProTM controls two computers with only one keyboard and mouse
  • 5 programmable Picture Mode profiles for quick access to multiple colour spaces
  • Picture in Picture and Picture by Picture modes increase productivity by displaying two sources simultaneously
  • MultiProfiler provides complete control over picture modes, enables real-time print emulation and can automate changing settings with keyboard shortcuts
  • Wide connectivity includes 10-bit DisplayPort and HDMI as well as VGA, and DVI-D inputs

What's Included

24.1" LCD Monitor
Power cord
DisplayPort cable
Mini DisplayPort cable
USB 3.0 A to B cable
SpectraView software USB drive
NEC custom calibrator
Individual factory calibration sheet

Reviews

Product Specifications

NEC PA243W-BK-SV 24.1" 16:10 IPS, 99.8% Adobe RBG, 95.5% DCI-P3, LCD Monitor with Spectra View II

Display


Panel Technology AH-IPS
Aspect Ratio 16:10
Pixel Pitch 0.27mm
Backlight Type Wide Gamut W-LED
Contrast Ratio (typical) 1000:1
Displayable Colours 1.07 billion out of 4.3 trillion (10 bit DisplayPort or HDMI) / 16.7 million out 1.05 billion (8-bit)
Viewable Image 24.1"
Native Resolution 1920 x 1200
Pixels Per Inch 93@ native resolution
Brightness (typical) 350cd/m2
Viewing Angle (typical) 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Lookup Table 14-bit (3D)
Colour Gamut Adobe RGB 99.6% / 112.4%
NTSC 100.0% / 151.6%
sRGB 100.0% / 151.6%

Synchronization Range


Horizontal (Analog/Digital) 31.5-118.4 kHz /31.5-118.4 kHz
Vertical 50-85 Hz

Signal Compatibility/Connectivity


Input Terminals DisplayPort, DVI-D, HDMI, VGA, USB 3.1 hub 2 up/ 3 down) with DisplaySync Pro

Power Consumption (typical)


On 35W
Power Savings Mode 0.3W

Physical Specifications


Dimensions (W x H x D) with Stand 556.2 x 379.1 - 529.1 x 233.0 mm
Dimensions (W x H x D) without Stand 556.2 x 361.8 x 58.6 mm (21.9 x 14.2 x 2.3")
Weight with Stand 8.0 kg (17.6 lbs)
Weight without Stand 5.2 kg (11.5 lbs)
VESA Hole Configuration 100 x 100 mm

Environmental Compliance


RoHS Yes
