Product Highlights
  • CMOS Sensor
  • Half-cardioid Polar Pattern
  • 100 ~ 240 VAC / 12 V DC Power
  • 20 Hz to 20 kHz Frequency Response
  • 2 MP Optical Resolution
  • Full HD video Recording
  • 48.5 x 18.8 x 15.9 cm (19.1 x 7.39 x 6.26") Dimensions
  • 1.04 kg (2.29 lbs) Weight
Model:
Turret
Audio Video Streamer
Umpire USB Mic
Marantz Broadcast Video Streaming System Includes Webcam System with Ring Light Marantz Broadcast Video Streaming Syst...
FREE SHIPPING Available
Web Availability: In Stock
Product is In Stock in our Warehouse or in one of our store locations. We will confirm stock is available and process your order. If the available stock is sold before your order is processed, you will receive an email from us.
In-store or Curbside Pick-up
  • Available in Toronto
Vistek Locations
  • Toronto In Stock
  • Ottawa Available for Order
  • Mississauga Available for Order
  • Calgary Available for Order
  • Edmonton Available for Order
Please call and verify availability at the store as stock changes daily.

Overview

AVS

Audio-Video Streamer

The Marantz AVS is an all-in-one broadcast system that offers the live streamer professional components in a compact, free-standing array.

Key Features:

  • All-in-one, freestanding broadcasting system
  • Full HD webcam with H.264 video compression
  • High-quality USB condenser boundary microphone (48kHz/16-bit) built into base
  • Dimmable LED light ring / daylight-balanced with cool, warm and diffusion filter accessories
  • USB-C output to computer for high-speed, low-latency
  • Internal USB hub
  • Headphone amplifier

The AVS features a full HD webcam compatible with H.264 video compression, a high-quality 48kHz/16-bit USB condenser boundary microphone conveniently integrated into the base of the unit, and an LED light ring, daylight-balanced, with both cool and warm filter accessories for the look of a studio production.

The Marantz AVS is a unique, all-in-one broadcast tool that is designed for live-streaming, video calling and gaming applications. It is compact and simple, perfect on a desktop, and the lightweight design makes it portable enough to take on location.

To make the system truly self-contained and capable of handling any streaming/podcast task without the need for additional equipment, the AVS has a high-speed USB-C computer output for low latency and an internal USB hub.

There is even an onboard headphone amplifier so audio monitoring is simple. Everything the demanding streaming/broadcasting enthusiast needs is right here, in one convenient, high-performance package.

Reviews

Product Specifications

AVS

Camera


Focus Fixed-focus
Sensor CMOS Sensor
Diagonal field of view 70 °
Optical resolution 2MP native
Full HD 1080p video Up to 1920 x 1080 pixels recording
Frame rate 30 fps/1080p, 30 fps/720p
Video compression H.264 video compression
ON/OFF switch Yes
Automatic low-light and white balance correction Yes
System compatibility Windows® XP, 7, 8, 10, Mac OS X, LINUX, Android
Operates in USB Video Device Class (UVC) mode Operates in USB Video Device Class (UVC) mode
USB 2.0 – Class 2 Compliant Driver USB 2.0 – Class 2 Compliant Driver

Boundary Microphone


Element Back electret condenser
Polar pattern Half-cardioid (cardioid in hemisphere above mounting surface)
Open Circuit Sensitivity -44dB ± 3dB (0db = 1V/Pa @ 1KHZ)
Output impedance 2.2 kΩ ± 30% (@ 1kHz)
Sample rate 32 kHz / 44.1 kHz / 48 kHz @16-bit
Frequency response 150 Hz - 10 kHz
Signal-to-Noise Ratio >60 dB (1kHz @ 1% THD)
Max SPL 100 dB
ON/OFF switch Yes

Headphone Amplifier


Frequency Response 20 Hz – 20 kHz
Output power 130mW
Level control Yes
Stereo output 3.5mm stereo output
Mix control to mix microphone audio with USB audio input Mix control to mix microphone audio with USB audio input

LED Light Ring


Light ring 4" dimmable LED light ring
30x wide-angle white LEDs @ 5600K (30) wide-angle white LEDs @ 5600K

Accessory filters


3x Accessory Filters Diffused daylight
Cool
Warm

USB


USB 1 & 2 2x Type A USB 3.0, 0.75A total available current between two ports for powering devices
To PC 1x USB-C connector / USB 3.0 connection
USB Audio In Class 2 compliant speaker device for audio to be monitored in headphone output – set by user in the computer

Microphone Auxiliary Output


Microphone Auxiliary Output Fixed line-level output on 3.5mm TRS jack

Physical Specs


Dimensions (WxHxD) 188 x 485 x 159 mm (7.39 x 19.1 x 6.26")
Weight 2.29 lbs (1.04kg)
Power AC-DC power supply
100 ~ 240 VAC compatible
12 VDC @ 1 amp output
