Product Highlights
  • 5" Touchscreen Monitor / Recorder
  • 1920 x 1080 Resolution
  • In-Plane Switching IPS Technology
  • HDMI 2.0 Input / Output
  • 1000 cd/m² Brightness
  • 16:9 Aspect Ratio
  • 1.07 Billion Colours
  • 2.5" SSD / HDD Storage
  • Includes Ninja V, Master Caddy II, Power Supply & Accessory Kit
Atomos Ninja V 5" HDR Monitor - 4K60P ProRes Recorder Bundle w/ Accessory Kit Atomos Ninja V 5" HDR Monitor - 4K60P...
FREE SHIPPING Available
Web Availability: Special Order
Vistek Locations
  • Toronto Special Order
  • Ottawa Special Order
  • Mississauga Special Order
  • Calgary Special Order
  • Edmonton Special Order
Please call and verify availability at the store as stock changes daily.

Overview

Ninja V 5" HDR Monitor w/ Accessory Kit

Record like a Ninja

Eliminate your camera’s internal compression and time limits – record up to 4Kp60 10-bit HDR video direct from your camera's sensor over HDMI 2.0. Teamed with a 1TB AtomX SSDmini you can now achieve up to 150 minutes of 4K recording on a single drive! And when you’re done, your edit-ready ProRes and DNxHR recordings are stored on affordable SSD drives.

HDR/SDR perfection

The Ninja V displays 10+ stops of dynamic range in realtime from Log/ PQ/HLG signals. See your images clearly in daylight on the near edge-to-edge anti-reflection screen. Ninja V can be calibrated for perfect color accuracy every time, and also enables playout to HDR or SDR TV.

Compact Monitor Recorder made perfect

The new Ninja V features a stunningly bright 5.2” 10-bit HDR monitor with an astounding 1000 nits of output. The sleek aluminium body is crafted for maximum durability, weighing in at just 360g and measuring only 25mm thick – easily attaching to any camera rig.

Pocket size playback

AtomOS allows accurate set up and one-touch operation, ensuring a great recording every time. Of course, a recording isn't complete until checked; Ninja V allows instant playback, slow motion and frame-by-frame analysis for immediate review.

Record 4K HDR Gaming

Ninja V is a stand-alone system for 4k UHD, HDR and high frame rate capture that eliminates expensive, complicated and unreliable PC setups. Ninja V enables simple recording, monitoring and instant review. Capture every detail in HDR and automatically include all the correct HDR flags ready for upload to YouTube. Ideal for games development testing, pre-release capture sessions or just to show off your skills.

Edit, finish & upload

Ninja V files are available immediately on your Mac or PC. Tag on-the-fly while recording for direct-to-edit look up in Final Cut Pro X, Adobe Premiere and Avid Media Composer. Both video and gaming workflows are supported for the fastest path to your audience.

SSD made Mini

We have worked closely with our drive partners at Angelbird and Sony to bring you the AtomX SSDmini. These tiny drives are only 7mm high and 80mm long. They retain the same SATA III connector as traditional SSDs and they are backward compatible with our range of Ninja, Shogun and Sumo devices.

Endless Open Expansion

Modularity is at the heart of the Ninja V with a bi-directional high speed expansion port breaking out connectivity for I/O of video, audio and power. Atomos created AtomX to ensure users could adapt and connect to any legacy or future wireless or wired video standard. The expansion system offers endless scalability and is demonstrated by the first of many modules - the AtomX Ethernet/NDI® $199 and the AtomX Sync $149 announced at IBC 2018. These dock into the AtomX port and instantly add important features like NDI® over ethernet and Wireless Sync and Bluetooth control to the Ninja V.

Looks good, sounds great

Like all Atomos Monitor/Recorders, Ninja V enables audio input directly from your camera. Choose from digital source via HDMI, or analogue input via the stereo 3.5mm line/mic socket, depending on your rig.

Ninja V + ProRes RAW

Photographers have long known about the benefits of RAW for stills, now Nikon Z series users will be able to get the same power of RAW in video. Capturing Apple ProRes RAW video with the Ninja V unlocks complete control of the video image at the highest quality possible. The maximum dynamic range, color accuracy and detail is preserved, while at the same time every aspect of the video image can be controlled with precision for maximum creativity. Colors can be easily matched and the extra information means footage can be easily be manipulated in post-production, which is especially useful for grading and VFX shots. – read more about ProRes RAW.

What's Included

Ninja V Unit
Master Caddy II
12V / 3A Power Supply
Battery Eliminator Quick Start Guide
Accessory Kit
2x Batteries
Charger
Power Supply
Sun Hood
Screen Protector
Travel Case

Reviews

Product Specifications

Ninja V 5" HDR Monitor w/ Accessory Kit

Physical Specifications


Without batteries & media 630g / 22.2oz
Dimensions (W x H x D mm) 151 x 91.5 x 31mm, 8.4 x 5 x 1.8”
Construction Aluminium alloy chassis with ABS polycarbonate back plate
Mounting points 1/4-20 UNCscrew mount; 1x top, 1x bottom

Power


Operating power 10 - 19W
Compatible batteries NP-F series and supporting accessories
Input voltage (battery) 6.2V to 16.8V
Battery Time (based on 2x 7.4 V batteries) 5200mAh - up to 2 hrs (monitor & record 4K 60p)
7800mAh - up to 3 hrs (monitor & record 4K 60p)
Continuous power
(Patent pending)
Continuous power with external adaptor

Touchscreen


Size 5”
Resolution 1920 x 1080
PPI 427
Aspect ratio 16:9 native
Colour Gamut REC709 HDTV
Look up table (LUT) support 3D LUT (.cube format)
Anamorphic de-squeeze 2x, 1.5x, 1.33x, Panasonic 8:3
Technology SuperAtom IPS panel (capacitive touch),
calibration to Rec.709 with optional calibration unit

HDR


AtomHDR Yes
Supported Log formats Sony SLog2 / SLog3, Canon CLog / CLog 2, Arri Log C,
Panasonic Vlog, JVC JLog, Red LogFilm, FujiFilm Flog,
Nikon N-Log
HDR Recording (Gamut) Sony SLog / SLog2 / SLog3, Canon CLog / CLog2 / Clog3,
Arri Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320
/ LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 /
LogCEI1000 / LogCEI1280 / LogCEI1600, Panasonic Vlog,
JVC JLog1, Red LogFilm / Log3G10 / Log3G12, FujiFilm
Flog, PQ10k, HLG, Nikon N-Log
HDR Monitoring (Gamma) Sony SGamut / SGamut3 / SGamut3.cine / BT2020
Canon Cinema / DCI P3 / DCI P3+ / BT2020
Panasonic V Gamut
Arri Alexa Wide Gamut
Rec709
JVC LS300
Red DragonColor / DragonColor2 / RedColor2 /
RedColor3 / RedColor4 / RedWideGamut
HDR Monitoring (Gamut) Wide Color Gamut (SGamut / SGamut3 / SGamut3.cine / Canon Cinema / BT2020 / DCI P3 / DCI P3+ / Panasonic V Gamut / Arri Alexa Wide Gamut) mapping to Rec709 on screen Wide Color Gamut (SGamut / SGamut3 / SGamut3.cine / Canon Cinema / BT2020 / DCI P3 / DCI P3+ / Panasonic V Gamut / Arri Alexa Wide Gamut) mapping to Rec709 / BT2020 / DCI P3 on loop out
Bit depth 10-bit (8+2 FRC)
Brightness 1000nit (+/- 10% @ center)
HDR input (PQ/HLG)
HDR output (PQ/HLG)
Yes / Yes
Yes / Yes

Video Input / Loop Out


HDMI HDMI 2.0
Signal Uncompressed true 10-bit or 8-bit 422
(camera dependent)

Video Output (Play Out)


HDMI HDMI 2.0
Signal Uncompressed true 10-bit or 8-bit 422
(playback file dependent)

Supported Loop Out Formats


HDMI to HDMI 720p 50/60, 1080i 50/60,
1080p 24/25/30/50/60/100/120
2160p 24/25/30/50/60

AtomX Expansion Port - Video, Audio & Power In / Out


Video Up to 4Kp60
Audio 12 channels digital 24-bit 96 kHz
Power 5 V - 16.6 V

Supported Codecs & Frame Rates (Record & Playback)

Video to ProRes / DNxHR
(DNx utilizes a .MOV wrapper)
Apple ProRes HQ, 422, LT AVID DNxHR HQX. HQ, SQ, LB
4K DCI; 24/25/30/50/60p
4K UHD; 24/25/30/50/60p
2K
1080p; 24/25/30/50/60/100^/120^
1080i; 50/60i, 720p; 50/60p


Onboard Processing


Pulldown removal 24/25/30pSF > 24/25/30p (2:2 pulldown)
60i > 24p (3:2 pulldown)
4K UHD downscale for HD Monitoring Yes - Loop-out and playback

Audio In / Out (48 kHz PCM Audio)


HDMI 2 or 8ch 24-bit, camera dependent
Audio Line in / Mic in / Headphone out 2ch 48kHz 24-bit
Headphone Out 3.5 mm

Remote Start / Stop


HDMI Auto HDMI Trigger
Supported Protocols - Canon, Sony, Atomos Open Standard
Other LANC control - Slave

Playback


Playlist / Genlock / LTC Yes / - / -
CDNG (Recorded content) N/A
ProRes (Recorded content) All recorded files can playback. Playback in slow motion
DNxHR / DNxHD (recorded content) All recorded files can playback. Playback in slow motion

Recording


Pre-roll record Yes (HD 8s, 4K 2s)
Custom timelapse Yes
Meta data tagging Yes (10 tags available)
Supported media 2.5” SSD/HDD compatibility depends on recording format, resolution and frame rate.
Master caddy case Master Caddy II (included)
75mm x 105mm x 12mm
Master caddy dock 2.5” SATA to USB 2.0/3.0
Supported applications Supported Applications FCPX/FCP7+ / Media Composer
5.0+ / Premiere 5.5+
EDIUS 6.0+ / Vegas Pro 10+ / Lightworks /
Autodesk Smoke 2015
XML support FCPX XML native, FCPX/Adobe limited supported with 3rd party conversion tools
