- Webcode: 441813 • Mfr: PTR-10T MK II
- FREE SHIPPING Available
Product Highlights
- 4 kg (9 lbs) Max. Load Capacity
- 1200 m (3937') Control Distance
- HDMI / SDI / RJ45 Interface
- HDBaseT / RS-422 Input
- ±45° Tilt Range
- 12 VDC Power
- 3 kg (6.6 lbs) Weight
- Aluminum Material Construction
Datavideo PTR-10T Robotic Pan and Tilt Head with HDBaseT for HS-1600MKII
Datavideo PTR-10T Robotic Pan and Tilt H...- Toronto Special Order
- Ottawa Special Order
- Mississauga Special Order
- Calgary Special Order
- Edmonton Special Order
Lease this for: $122.52 Learn More
Overview
PTR-10T Mark II Pan Tilt Head
A sleek design fits seamlessly in your studio. With its weight of 3.4 Kg, it can be placed on any heavy-duty tripod or mounted on the wall and ceiling which brings up a lot of flexibility for your video production.
The PTR-10T MARK II can be controlled by the included IR controller, VISCA protocol controller, Datavideo RMC-180 Camera controller, RMC-300A Universal Remote-Control Panel, HS-1600T series and compatible with HDBaseT over Ethernet and other integration solutions such as Crestron.
Cost-Effective
PTR-10T MARK II makes the change from regular camcorder cameras to remote controlled PTZ very cost effective. Multi-camera remote operations can be handled by a single person.
Wide range of compatible cameras supported
The PTR-10T Mark II implements LanC control that is compatible with a wide range of professional video camcorders, allowing you to select the best camcorders for your needs.
Lightweight, strong & sturdy design
With a weight of 3.4 kg, PTR-10T MARK II is built from aluminum alloy, making it a very sturdy base for your camera. It can support cameras up to 4 kg (8.8 lbs).
Diversified Controller Options
Compatible with Serial, Ethernet, and Lanc. Datavideo RMC-180 series, RMC-300A, and HS-1600T series will fit your need.
Built-in tally light
With the big tally light in the front to show the status of your camera.
D-tap connector for DC output
The D-tap connector is widely used in the broadcast industry as a standard for powering accessories from battery or mains power. This will make it easier for you to find a ready-made power cable for your specific camera. Included is a D-tap to DC 5.5mm with lock for Datavideo cameras.
Multiple signal interface
PTR-10T MARK II supports a lot of signal interface for passing through the remote head. Amongst these interfaces are SDI, HDMI, RS-232, RS-422, HDBaseT, Tally, and LANC.
Optional Accessories: ZEK-1 Zoom Encoder Kit
ZEK-1 is the solution to your free running Zoom cameras. PTR-10T MARK II can read its own Pan/Tilt movement and send back to controller for position memory and recall. Now, with ZEK-1, it can detect and read out the Zoom changes. And convert those information into Zoom position to send back for controller to memory and recall the saved zoom position. Compatible with cameras via zoom moving ring.
What's Included
PTR-10T Mark II Main UnitDC 12V power adaptor
AC cord
IR remote control
DC with lock to D-Tap cable
HDMI cable
SDI cable
Remote cable (2.5mm phone-jack to mini-din 8pin)
2x 1/4” screws (14mm)
1/4” screw (10mm)
1/4” to 3/8” screw adaptor
Reviews
Product Specifications
PTR-10T Mark II Robotic Pan Tilt Head |
|
|---|---|
| Video Interface | HDMI SDI RJ45 (HDBaseT) |
| Video Output | 2160p 29.97/25 1080p 59.94/50 1080i 59.94/50 720p 59.94/50 |
| Control Unit | RMC-180 HS-1600T HS-1600T Mark II RMC-300A VISCA Protocol Controller IP Control IR remote |
| Panning / Tilting Range | Pan: 340° Tilt: ±45° |
| Panning / Tilting Speed | Pan: 0.12~15° /Sec Tilt: 0.06~10° /Sec |
| Preset | Pan/Tilt position 50 |
| Control Distance | 1,200M by RS422 100M by DVIP |
| Control Protocol | Sony VISCA DVIP |
| Control Input | RS-422 HDBaseT |
| Maximum Load | 4 kg (8.8 lbs) |
| Control Output | RS-232 RS-422 BX-Lens LanC |
| Power Requirement | DC 12V~ 18V, 3A (Without Camera) DC 12V~ 18V, 5A (With Camera) |
| Power Supply | DC 12/10/8.4/7.4V, 24W Max |
| Operating Temperature Range | 0~40 C° |
| Operating Humidity Range | 10~80% |
| Storage Temperature Range | -10~60C° |
| Storage Humidity Range | 5~80% |
| Weight | 3.4 kg (7.4 lbs) |
| Dimensions | 230 x 190 x 300 mm |
