- Webcode: 406686 • Mfr: V-MD241
- FREE SHIPPING Available
Product Highlights
- 24" Modular Design Monitor
- 1920 x 1080 Resolution
- 300 cd/m² Brightness
- 3000:1 Contrast Ratio
- 4-Pin Female XLR / Ethernet / SDI Connection
- LED Backlight
- 178° View Angle
Marshall Electronics 24" Modular Design Monitor with Composite and Component inputs
Marshall Electronics 24" Modular Design Monitor wit...
$2,919.00
Add to Cart
FREE SHIPPING
Available
Web Availability:
Special Order
This product will be Special Ordered just for you from the manufacturer. We do not stock this item due to its uniqueness or import schedule. Special Order items are Final Sale, see our Return Policy for details.
Vistek Locations
- Toronto Special Order
- Ottawa Special Order
- Mississauga Special Order
- Calgary Special Order
- Edmonton Special Order
Lease this for: $111.80 Learn More
Overview
24" Modular Design Monitor
24", 1920x1080 Resolution Rack mountable Desktop / VESA Mount Monitor Monitor with Modular Inputs and Network Control.
Key Features:
- Swap and interchangeable video modules
- Native 1920 x 1080 resolution screen
- Two available input slots
Reviews
Product Specifications
V-MD241 24" Modular Design Monitor |
|
|---|---|
Panel |
|
| Number of Panels | 1 |
| Panel Size | 24” Diagonal |
| Resolution | 1920 x 1080 |
| Aspect Ratio | 16:09 |
| Active Area | 531.36 x 298.89 mm |
| Type | LCD Panel |
| Brightness | 300 cd/m² |
| Contrast | 3000:1 |
| Colour Gamut | YUV, RGB |
| Viewing Angles (CR>=10) | 178° x 178° |
| Backlight type | LED |
| Adjustable Backlight | Yes |
Features |
|
| Video Formats | 1080p/1080i/720p/625i/525i |
| Loss of Input Curtain | Yes |
| Color Temperature | D65, D55 and D93 |
| H/V Delay | Yes |
| Under scan | Yes |
| IMD Functions | Yes |
| Tally | Yes |
| False | Yes |
| Peaking Filter | No |
| HDMI CSC Auto | With HDMI Module |
| HDMI Ratio Auto | With HDMI Module |
| Pixel to Pixel | Yes |
| Test Signals | No |
| Pre-set Gamma points | No |
| Self-Sensing | Yes |
| Modular Input Slot | 2 |
| Re-clocked/Re-Shaped | Yes |
Video Input Connectors |
|
| CVBS | Yes |
| YPbPr | Yes |
| SD-SDI | Optional Module |
| HD-SDI | Optional Module |
| 3G-SDI | Optional Module |
| HDMI | Optional Module |
| DVI-I | Optional Module |
| Optical | Optional Module |
Video Output Connectors |
|
| CVBS | Yes |
| YpbPr | Yes |
| SD-SDI | Optional Module |
| HD-SDI | Optional Module |
| 3G-SDI | Optional Module |
| HDMI | No |
Control Inputs |
|
| Embedded Audio from SDI | Yes |
| Input Status Display | Yes |
| Tally / GPI | Tally |
| RS-485/422 w/ Loop-Through | No |
| Ethernet | Yes |
Mechanical |
|
| Controls on front Panel | Yes |
| User-Defined Function Buttons | Yes |
| RotoMenu™ Control | No |
| Pivot Angle | Yes |
| Handles/Rack Ears | Yes |
Power |
|
| Voltage | 12 VDC |
| Consumption | 3.5A @ 12VDC (42 W) |
| Power Switch | Yes |
| Connector | 4-Pin Female XLR |
Compliance |
|
| Compliance | CE approved |
Environmental |
|
| Operating Temperature (C°) | 32°F to 104°F |
| Storage Temperature (C°) | -4°F to 120°F |
| Rack Unit dimensions (WxHxD) | 22 x 14.66 x 1.5" |
| Weight (Main Body) | 11.05 lbs |
| Protective screen | No |
| Vesa Mount Pattern | 200/75mm |
