Product Highlights
  • 3G/HD/SD-SDI to HDMI Conversion
  • 3G/HD/SD-SDI Video Inputs
  • HDMI Video Outputs
  • 2x SDI Audio Inputs
  • 2x HDMI / 2x RCA Audio Outputs
  • 12 VDC Power
  • 400 g (14 oz) Weight
  • 11 x 8.5 x 4.5 cm (4 x 3 x 2") Dimensions
Datavideo DAC8PA HD/SD-SDI to HDMI Converter Datavideo DAC8PA HD/SD-SDI to HDMI Conve...
$349.99 Add to Cart
Add to Wishlist
FREE SHIPPING Available
Find it for less? Let us know.
Web Availability: Special Order
This product will be Special Ordered just for you from the manufacturer. We do not stock this item due to its uniqueness or import schedule. Special Order items are Final Sale, see our Return Policy for details.
Vistek Locations
  • Toronto Special Order
  • Ottawa Special Order
  • Mississauga Special Order
  • Calgary Special Order
  • Edmonton Special Order
Please call and verify availability at the store as stock changes daily.

Overview

SDI to HDMI Converter

Convert SDI to HDMI with audio de-embedding options

The DAC-8PA allows you to convert an SDI signal (up to 1080p60) to HDMI. It includes the option to de-embed audio to a stereo RCA output.

Supports 1080p 50/60

Automatic input signal and colour depth detection with support for Deep Color

Supports SDI Loop-Through Output

Simultaneous SDI loop-through with HDMI output

Aluminum Alloy and Heavy Duty Design

Super sturdy and durable. The DAC series has a rugged metal housing for use in even the roughest conditions. Low heat dissipation, ideal for long hour operation in normal ventilated environment.

What's Included

DAC-8PA product
AD Switch DC 12V

Reviews

Product Specifications

DAC-8PA SDI to HDMI Converter
Conversion 3G/ HD/SD-SDI to HDMI
Video Inputs 3G/HD/SD-SDI
Loop Through 1
Video Outputs HDMI with embedded Audio
Audio Inputs 2x SDI Audio embedded
Audio Outputs 2x RCA (Stereo Pair)
2x HDMI Audio embedded
Supported Video Input Formats 1080p (23.98/24/25/29.97/30/50/59.94/60Hz),
1080i (50/59.94/60Hz),
720p (50/59.94/60Hz),
625i 50 (PAL), 525i 59.94 (NTSC)
Output Resolutions Automatically matches the SD, HD and 3G SDI video input
Equalizer Yes
Reclock Yes
SDI Cable Drive Yes
Weight 0.4 kg (0.88 lbs)
Dimensions 11.2 x 8.5 x 4.5 cm (4.4 x 3.3 x 1.7")
Operating Temperature Range 0~40 °C
Power DC 12V, 4W
