Product Highlights
- 8.46 MP 1/2.8" CMOS Sensor
- Up To 3840 x 2160 Max. Resolution
- 0.5Lux Min. Illumination
- HDMI / Ethernet Interface
- 6.7 W Max. Power
- CS/C Lens Mount
Marshall Electronics CV374 Compact 4K (UHD60) Camera CS mount with NDI| HX3 + HDMI
Marshall Electronics CV374 Compact 4K (UHD60) Camer...- Toronto Special Order
- Ottawa Special Order
- Mississauga Special Order
- Calgary Special Order
- Edmonton Special Order
Overview
CV374
Compact 4K Camera CS Mount with NDI|HX3+HDMI
The Marshall CV374 network streaming POV camera is built around a Sony UHD sensor with over 8.46 million pixels. The compact CV374 delivers exceptional 4K (UHD) video performance via HDMI and ethernet IP interface supporting the ultra-efficient NDI HX3, SRT, HEVC codecs from a durable aluminum alloy build with rear I/O protection wings. The Ultra-HD Sony sensor offers crystal clear and rich color accurate video with improved low light sensitivity, refined remote adjust capability and flexible interchangeable lenses.
NDI HX3 Premium, Efficient, Low Latency, Loss-less Streaming Codec
Featuring the extremely efficient NDI HX3 codecs gives the compact CV374 camera a unique advantage over other streaming cameras with 100ms end-to-end of latency using less bandwidth and maintaining the premium video quality of the source. Simultaneous HDMI output and other streaming options such as SRT, RTSP, RTMP, HEVC and more.
Flexible Interchangeable CS/C Mount Lenses
Marshall CV374 compact cameras are built with a CS/C lens mount with optional DC Auto Iris. Marshall offers a wide selection of high-quality CS and C mount prime and varifocal lenses to meet the individual needs of the production, project, or application. CV374 are perfectly setup for longer throws and telephoto lenses.
Durable, Flexible, Powerful
The compact CV374 body is chiseled from a block of aluminum alloy making it extremely durable in a discreet compact size with rear I/O protection. CV374 operates with exceptional low-light sensitivity, ensuring a clear picture in challenging lighting conditions with refined remote adjust & match capability over network or Visca over IP commands. Suitable for a variety of AV over IP network, cloud production, remote contribution, and HDMI workflows.
Broadcast Performance
Marshall Camera Division continues to develop camera products to follow the heritage of Marshall broadcast quality incorporating reliability, durability, flexibility and most importantly affordability with feature sets that matter to our industry partners.
What's Included
CV374 Compact 4K Camera CS Mount with NDI|HX3+HDMII/O Breakout Cable
Power Adapter
Reviews
Product Specifications
CV374 Compact 4K Camera CS Mount with NDI|HX3+HDMI |
|
|---|---|
Sensor |
|
| Image Sensor | 1/2.8” Progressive CMOS (Approx. 8.46 mega) |
| Scanning System | 16:9 Progressive |
| Sync. System | Internal |
| Effective Pixel | 3840(H) x 2160(V) |
| Min. Illumination | 0.5Lux (Day), 0.01Lux (Night) |
Optics |
|
| Lens | CS Mount Compatible |
Functions |
|
| Back Light Compensation | WDR, BLC |
| Exposure | Auto / Manual |
| White Balance | AUTO / Manual / Indoor / Outdoor / One Push / AUTO Tracking (ATW) |
| Day & Night System | Day / Night:TDN(ICR) |
| Electronic Shutter | 1/30~1/10000 |
| Functions | Image Mirror/Flip, 2D+3DNR, Anti Flicker |
Ethernet |
|
| IP Protocols | NDI|HX2, NDI|HX3, SRT, RTMP, RTSP |
| Video encode format | H.264 / H.265 |
Video Output |
|
| Interfaces | HDMI, Ethernet |
Output Resolution |
|
| HDMI | 2160p25/29.97/30/50/59.94/60, 1080p23.98/24/25/29.97/30/5 0/59.94/60, 1080i50/59.94/60, 720p25/29.97/30/50/59.94/60 |
| IP | 2160p25/29.97/30/50/59.94/60, 1080p23.98/24/25/29.97/30/5 0/59.94/60, 720p25/29.97/30/50/59.94/60 |
| NDI|HX2 | 2160p25/29.97/30/50/59.94/60,1080p23.98/24/25/29.97/30/50/59.94/60, 720p25/29.97/30/50/59.94/60 |
| NDI|HX3 | 1080p50/60 |
Audio Input |
|
| Line Level | 16kHz, 32kHz, 48kHz sample rates |
Control |
|
| Network | Web GUI / VISCA over IP |
General |
|
| Operation Temperature | 0˚c ~ 50˚c |
| Power Input | 12VDC (10V to 13.5VDC) |
| Power Consumption | 12VDC power: 5.625W, POE power: 6.7W |
| Dimensions | 99.08mm(L) x 56mm(W) x 56mm(H) (without lens) |
| Weight | 0.8 lbs (without lens) |
