Q10 0.1" HDMI 2.0 / 2x 12G-SDI Ultra High Brightness On-camera Monitor
Q10 0.1" HDMI 2.0 / 2x 12G-SDI Ultra High Brightness On-camera Monitor
Q10 0.1" HDMI 2.0 / 2x 12G-SDI Ultra High Brightness On-camera Monitor
Q10 0.1" HDMI 2.0 / 2x 12G-SDI Ultra High Brightness On-camera Monitor
No Reviews Q & A
Write your Review
Product Highlights
  • 10.1" On-Camera Monitor
  • 1920 x 1200 Max. Resolution
  • 1500 nits Brightness
  • 2x 12G-SDI / HDMI 2.0 Input / Output
  • 1000:1 Contrast
  • 170° View Angle
Lilliput Q10 0.1" HDMI 2.0 / 2x 12G-SDI Ultra High Brightness On-camera Monitor Lilliput Q10 0.1" HDMI 2.0 / 2x 12G-SDI...
$1,589.00 Add to Cart
Add to Wishlist
FREE SHIPPING Available
Find it for less? Let us know.
Web Availability: Special Order
This product will be Special Ordered just for you from the manufacturer. We do not stock this item due to its uniqueness or import schedule. Special Order items are Final Sale, see our Return Policy for details.
Vistek Locations
  • Toronto Special Order
  • Ottawa Special Order
  • Mississauga Special Order
  • Calgary Special Order
  • Edmonton Special Order
Please call and verify availability at the store as stock changes daily.
Lease this for: $64.51 Learn More

Overview

Q10 10.1" High Brightness 12G-SDI / HDMI 4K Monitor

The Lilliput Q10 is a professional camera-top monitor specifically designed for photography and film makers. Fitted with an amazing 1500 nit Ultra Bright LCD screen, it is especially geared for outdoor video and film shooting. The 10.1" LCD panel has 1920×1200 Full HD native resolution and with 200:1 high-contrast it provides crystal-sharp superior picture quality.

Supporting 4K HDMI 2.0 and 12G-SDI signal inputs and loop outputs, it is possible to receive 2× 12G-SDI signals and display both at the same time via the picture-in-picture function, (the size and position of which can be adjusted) and HDMI signals up to 4K 60Hz through an HDMI 2.0 interface - making it compatible with the very latest DSLR cameras on the market

Reviews

Product Specifications



Q10 10.1" High Brightness 12G-SDI / HDMI 4K Monitor

Display


Panel 10.1”
Physical Resolution 1920×1200
Aspect Ratio 16:10
Brightness 1500 nit
Contrast 1000:1
Viewing Angle 170°/ 170°(H/V)
HDR ST2084 300/1000/10000/HLG
Supported Log formats SLog2 / SLog3 / CLog / NLog / ArriLog / JLog or User…
Look up table (LUT) support 3D LUT (.cube format)

Signal Input


SDI 2×12G-SDI
HDMI 1×HDMI 2.0
Tally 1

Signal Loop Output


SDI 2×12G-SDI
HDMI 1×HDMI 2.0

Support Formats


SDI 2160p 60/50/30/25/24, 1080p 60/50/30/25/24, 1080pSF 30/25/24,
1080i 60/50, 720p 60/50…
HDMI 2160p 60/50/30/25/24, 1080p 60/50/30/25/24, 1080i 60/50,
720p 60/50…

Audio In/Out


SDI 16ch 48kHz 24-bit
HDMI 8ch 24-bit
Ear Jack 3.5mm
Built-in Speakers 1

Power


Input Voltage DC 7-24V
Power Consumption ≤37W (12V)

Environment


Operating Temperature 0°C~50°C
Storage Temperature -20°C~60°C

Other


Dimension (LWD) 251mm × 170mm × 30.5mm
Weight 1.1kg
