Product Highlights
  • 40 MP 1/1.8" CMOS Sensor
  • Up To 3840×2160 @ 30fps Max. Resolution
  • 3000 m (9842.5') Max. Range
  • ISO 100-819200 ISO Sensitivity
  • IP54 IP Rating
DJI Zenmuse H30T SP Plus DJI Zenmuse H30T SP Plus
$13,980.00 Add to Cart
Add to Wishlist
FREE SHIPPING Available
Find it for less? Let us know.
Web Availability: Special Order
This product will be Special Ordered just for you from the manufacturer. We do not stock this item due to its uniqueness or import schedule. Special Order items are Final Sale, see our Return Policy for details.
Vistek Locations
  • Toronto Special Order
  • Ottawa Special Order
  • Mississauga Special Order
  • Calgary Special Order
  • Edmonton Special Order
Please call and verify availability at the store as stock changes daily.

Overview

Zenmuse H30T SP Plus

Further and Clearer ‌Vision

40MP zoom camera supports up to 34× optical zoom and 400× digital. 3000m max laser rangefinding distance is an approx. 2.5-times increase.

Enhanced Night Vision

Zoom and wide camera support Night Scene mode to improve performance in low light. Zoom camera supports IR Light and NIR Illumination.

Powerful Infrared Performance

1280×1024 resolution is a 4x improvement. UHR Infrared Image function allows clear imaging at higher zoom. Max measurable temperature is 1600° C (2192° F), three times that of the previous generation.

Reliable Information Sync

Experience 30s max pre-recording, media and video transmission encryption with one-click log clearance, and live views via DJI FlightHub 2.

Smart Multi-Scenario Operation

Supports Smart Capture for detailed photos in dramatic lighting conditions. Electronic dehazing improves imaging clarity in haze/fog etc.

Environmental Adaptability

Dust and water resistance rated at IP54, and operational from -20° to 50° C (-4° to 122° F), meeting all-weather operational demands.

What's Included

Zenmuse H30T
Lens Cap
microSD Card
Storage Case
Lens Cleaning Cloth

Reviews

Product Specifications

Zenmuse H30T
Dimensions
  • 170×145×165 mm (L×W×H)
Weight
  • 920±5 g
Power
  • H30: 26 W
    H30T: 28 W
IP Rating IP 54
Supported Aircraft Matrice 400
Matrice 350 RTK
Matrice 300 RTK (requires DJI RC Plus)
Operating Environment
  • -20° to 50° C (-4° to 122° F)
Storage Environment
  • -20° to 60° C (-4° to 140° F)

Gimbal


Stabilization System
  • 3-axis (tilt, roll, pan)
Angular Vibration Range
  • Hover: ±0.002°
    Flight: ±0.004°
Mounting
  • Detachable DJI SKYPORT
Mechanical Range
  • Tilt: -132.5° to +73°
    Roll: ±60°
    Pan: ±328°
    (Structural limit, not controllable range)
Controllable Range
  • Tilt: -120° to +60°
    Pan: ±320°
Operation Mode
  • Follow/Free/Re-center

Zoom Camera


Sensor
  • 1/1.8-inch CMOS, Effective Pixels: 40 MP
Lens
  • Actual Focal Length: 7.1-172 mm (Equivalent focal length: 33.4-809.3 mm)
    Aperture: f/1.6-f/5.2
    DFOV: 66.7°-2.9°
Focus Mode
  • MF, AFC, AFS
Exposure Mode
  • Manual, Auto
Exposure Compensation
  • ±3.0 (1/3 increments)
Metering Mode
  • Spot Metering, Average Metering
AE Lock Supported
Electronic Shutter Speed
  • 1/8000-2 s
ISO Range
  • Single Shot: 100-25600
    Night Scene: 100-819200
Video Resolution
  • Single Shot: 3840×2160@30fps, 1920×1080@30fps
    Night Scene: 1920×1080@25fps, 1920×1080@15fps, 1920×1080@5fps
Video Format MP4
Video Subtitles
  • Supported

Video Codec and Bit Rate Strategy
  • H.264, H.265
    CBR, VBR
Max. Photo Size
  • 7328×5496, 3664×2748
Photo Format
  • JPG

Infrared Thermal Camera (H30T)


Thermal Imager
  • Uncooled VOx Microbolometer
Lens
  • Focal Length: 24 mm (equivalent focal length: 52 mm)
    Aperture: f/0.95
    DFOV: 45.2°
Digital Zoom Equivalent 32x
Video Resolution
  • 1280×1024@30fps
Video Format
  • MP4
Video Subtitles Supported

Video Codec and Bit Rate Strategy
  • H264, H265
    CBR, VBR
Photo Resolution
  • 1280×1024
Photo Format R-JPEG
Pixel Pitch
  • 12 μm
Spectral Band
  • 8-14 μm
Noise Equivalent Temperature Difference (NETD)
  • ≤ 50 mk@f/1.0

Temperature Measurement Method
  • Spot Measurement, Area Measurement, Center Point Temperature Measurement
Temperature Measurement Range
  • High Gain: -20° to 150° C (-4° to 302° F), -20° to 450° C (-4° to 842° F) (With Infrared Density Filter)
    Low Gain: 0° to 600° C (32° to 1112° F), 0° to 1600° C (32° to 2912° F) (With Infrared Density Filter)
Temperature Alert
  • Supported
Sun Burn Protection
  • Supported
FFC
  • Auto, Manual
Palette White Hot, Black Hot, Tint, Iron Red, Rainbow 1, Rainbow 2, Medical, Arctic, Fulgurite, Hot Iron

Laser Range Finder


Wavelength
  • 905 nm
Measurement Range 3-3000 m
Range for Common Objects: Grasslands 2000 m, woodlands 1900 m, road surfaces 1700 m‌
Measurement Accuracy
  • ≤ 500 m: ±(0.2 m+measurement distance×0.15%)
    ‌> 500 m: ±1.0 m
Laser Spot Size
  • @100 m: approx. 50×450 mm
    @1000 m: approx. 450×4500 mm
Safety Regulation Level
  • Class 1

Accessible Emission Limit (AEL)
  • 260 nJ
Reference Aperture
  • 18 mm

Max Laser Pulse Emission Power Within 5 Nanoseconds
  • 52 W

NIR Auxiliary Light


Wavelength
  • 850 nm
FOV
  • 4.6±0.6° (Round)
Safety Regulation Level Class 1
Illumination Range
  • @100 m: Approx. 8m diameter circle

Special Features


Hybrid Optical Zoom
  • 34×
Max Zoom
  • 400×
Link Zoom
  • Supported
Click to Aim
  • Supported
High-Res Grid Photo
  • Supported
Night Scene
  • Supported
Timestamp
  • Supported
Smart Capture
  • Supported
Video Pre-Recording
  • Supported
UHR Infrared Image
  • Supported

Data Storage


Supported microSD Cards
  • U3/Class10/V30 or above is required, or use a memory card from the recommended list.
Supported File System
  • exFAT

Recommended microSD Cards

 Lexar 1066x V30 A2 64GB/128GB/256GB/512GB microSDXC
Kingston CANVAS GO! Plus V30 A2 64GB/128GB/256GB/512GB microSDXC
