Canon EOS C50 7K Cinema Camera

DIGIC DV 7

Canon RF mount

• RF lens (including RF-S lens, RF cinema lens)
• EF lens (including EF-S lens, EF cinema lens (when equipped the RF-EF mount Adapter))
• PL lens (when equipped the Mount Adapter PL-RF)

Full frame CMOS sensor

Approx. 34.20 megapixels (7144x4790)

Sensor mode: Full frame 3:2

• Approx. 32.373 megapixels (6968x4646): 6960x4640 / 6912x4608 resolution

Sensor mode: Full frame

• Approx. 25.628 megapixels (6968x3678): 6960x3672 /4096x2160 / 2048x1080 resolution
• Approx. 24.032 megapixels (6534*1x3678): 3840x2160 / 1920x1080 resolution

Sensor mode: Super 35mm (Crop)

• Approx. 13.427 megapixels (5044x2662): 5036x2656 /4096x2160 /2048x1080 resolution

Sensor mode: Super 16mm (Crop)

• Approx. 3.388 megapixels (2532x1338): 2524x1332 /2048x1080 resolution
• Approx. 3.176 megapixels (2374*3x1338): 1920x1080 resolution

*1 Converted from 6968 pixels

*2 Converted from 5044 pixels

*3 Converted from 2532 pixels

5.16 X 5.16 (μm)

Sensor mode: Full frame 3:2

• 35.9 x 23.9 mm (43.2 mm on the diagonal): 6960x4640 resolution
• 35.7 x 23.8 mm (42.9 mm on the diagonal): 6912x4608 resolution

Sensor mode: Full frame

• 35.9 x 18.9 mm (40.6 mm on the diagonal): 6960x3672 /4096x2160 / 2048x1080 resolution
• 33.6 x 18.9 mm (38.6 mm on the diagonal): 3840x2160 / 1920x1080 resolution

Sensor mode: Super 35mm (Crop)

• 26.0 x 13.7 mm (29.4 mm on the diagonal): 5036x2656 /4096x2160 /2048x1080 resolution
• 24.4 x 13.7 mm (28.0 mm on the diagonal): 3840x2160 / 1920x1080 resolution

Sensor mode: Super 16mm (Crop)

• 13.0 x 6.9 mm (14.7 mm on the diagonal): 2524x1332 /2048x1080 resolution
• 12.2 x 6.9 mm (14.0 mm on the diagonal): 1920x1080 resolution

RGB primary colour filter (Bayer array)

Sensor mode: Full frame

• Canon Log 2: 1600% / 15+ stops (Base Sensitivity ISO 800)

Sensor mode: Super35mm

• Canon Log 2: 1600% / 16 stops (Base Sensitivity ISO 800)

Colour wide LCD monitor

3.0 inch (diagonal 7.5 cm)

Approx. 1.62 million dots (900xRGBx600)

100%

Brightness, Contrast, Colour, Sharpness, Luminance*

* A luminance boost function is also available that makes LCD monitor display easier to see outdoors and in other bright conditions."

Electrostatic capacitance system. Touch/drag operation supported.

Standards compliance: Follows the specifications of the Ethernet adapter

Supported standards: IEEE802.11b /g /n (2.4 GHz), IEEE802.11a / n / ac (5 GHz)

Compression method

• MPEG-4 H.264/AVC

Bit rate/Resolution

• 9 Mbps: 920x1080 (59.94P, 59.94i, 50.00P, 50.00i)
• 4 Mbps: same as above

Audio

• MPEG-2 ACC-LC 2ch

Audio rate

• 256 kbps

Protocols

• UDP: Prioritizes transfer speed, with no guarantees of reliability or correct order. Lost or lagging packets ignored.
• RTP: Standard system for sending videos and audio online. Lost or lagging packets ignored.
• SRT: Achieves high-quality streaming with minimal video distortion due to low latency and a packet loss playback function.
• RTP+FEC: Error correction (FEC)* control during RTP transfer enables recovery of lost or corrupt packets on the receiving side.
• RTSP+RTP: Real-time data streaming control via RTSP (Real Time Streaming Protocol) and transfer via RTP. The receiving side can start or stop streaming.

Type E3, Φ2.5 mm, stereo mini jack

USB Type-C jack
Can be used to connect a smartphone or Ethernet adapter. USB Video Class and USB Audio Class
(UVC and UAC) are supported.
In-camera charging and power supply are possible with USB Power Adapter PD-E2.
With an Ethernet adapter: equivalent to SuperSpeed USB (USB 3.2 Gen 1)

Canon original specifications

Battery terminal: DC 7.2 V (battery pack)

LP-E6P (provided with camera) /LP-E6NH*

Camera (Width x height x depth)

Approx. 143 x 88 x 95 mm (5.6 x 3.5 x 3.7 in.) (camera body only)

Approx. 222 x 239 x 186 mm (8.7 x 9.4 x 7.3 in.) (attached handle unit and Microphone holder)

* For dimension details, refer to the six-sided view.

(1) Camera

• Approx. 665 g (1.5 lb.)

(2) Camera+Handle unit+Microphone holder+Battery Pack LP E6P+CFexpresscard+SD card

• Approx. 1110 g (2.4 lb.)

(3) Supplied accessories

• Handle unit: Approx. 300 g (10.6 oz.)
• Microphone holder and two bolts: Approx. 60 g (2.1 oz.)
• LP-E6P Battery Pack: Approx. 82 g (2.89 oz.)
• LC-E6 Battery Charger: Approx. 110 g (3.9 oz.)
• LC-E6E Battery Charger: Approx. 100 g (3.5 oz.) (excluding power cord)

Operating Environment

Approx. 0 to 40°C (32 to 104 °F), 85% (relative humidity)

Approx. -5 to 45°C (23 to 113 °F), 60% (relative humidity)

Refer to the following table for the approximate continuous recording times when using the supplied LP-E6P Battery Pack or the optional LP-E6NH Battery Pack (fully charged). The values were measured while recording to a CFexpress card (second card recording functions turned off), with an RF50mm F1.8 L USM lens attached, with all settings other than those listed in the table set to default, and with no terminals connected.


Video

Recording Specifications

*Cfexpress only

Available Shooting Frame Rates

Crop Recording

Dual Pixel CMOS AF(CMOS AF)

• CMOS AF detection range
  • When detecting the entire area and subject, approx. 100% (Vertical) x approx. 100% (Horizontal).
  • Otherwise approx. 100% (Vertical) x approx. 90% (Horizontal)
  • May be approx. 100% (Vertical) x approx. 80% (Horizontal), approx. 75% (Vertical) x approx. 40% (Horizontal) depending on the lens

Applies when the AF/MF switch of an RF lens is set to AF.

• Continuous AF

Used to keep continuously focused on a subject.

• One-Shot AF

AF is performed only while the assignable button assigned to One-Shot AF is pressed. No further lens movement is permitted after focusing. Releasing the assignable button resumes continuous AF if it is enabled. When [Lens action if cannot AF] is set to [Stop] in Continuous AF mode, stop the search when distance measurement is not possible.

• Small Zone: Video display range approx. 14.7% (Vertical) x 12.2% (Horizontal)
• Flexible Zone 1: Video display range approx. 38% (Vertical) x 26% (Horizontal)
• Flexible Zone 2: Video display range approx. 85% (Vertical) x 26% (Horizontal)
• Flexible Zone 3: Video display range approx. 38% (Vertical) x 77% (Horizontal)
• Full: approx. 100% (Vertical) x approx. 100% (Horizontal)
• The area frame can be moved,* and thickness is adjustable. * Only with options other than [Whole Area] and when digital zoom is off.
• Area frame resizing is available for Flexible Zone options 1–3.
• Values above are based on these conditions: [Sensor Mode]: [Full Frame];
• [Main Resolution]: 4096x2160 or 2048x1080; [Electronic IS]: [Off]

Available

With compatible lenses, the lens drive speed is configurable.

Detects the eyes, face, head, or body of people or the eyes, face, or body of animals, as set in the menu. Setting to [People] targets human subjects for detection. Momentary inability to detect eyes / face / head will cause the camera to prioritize bodies (and when these parts can be detected again, they take precedence). Setting to [Animals] targets both animals and people for detection, and if both are detected, animals are given precedence. In scenes that include multiple subjects for detection, the most fitting main subject for detection results and how the shot is composed is automatically selected. Setting to [People] with autofocus active displays a white frame on the main subject and gray frames on all other subjects detected. Setting to [Animals] only displays a white frame on the main subject out of all animals and people detected.

Controls how AF operation changes, based on the menu setting, if targeted subjects are not detected. Setting to [Detect. Priority] performs AF for any detected main subjects set in [Subject to Detect], or if none are detected, in the specified AF area.

Setting to [Detect. Only] performs continuous AF restricted to main subjects set in [Subject to Detect]. The camera keeps focusing on the last detected position of any subjects that become undetectable. Continuous AF resumes when subjects are once again detected.

Enables adjustment of how readily the camera switches focus from one main subject to another. Set in a range of 1–5. [1] makes the camera less likely to switch subjects, and [5] makes switching easier.

Determines which eye is given precedence when two eyes are detected, as set in the menu.

Setting to [Auto] targets the eye closest to the camera. If both eyes are the same distance away, the camera targets the eye closer to the center of the configured AF area. Setting to [Right Eye Priority] gives the subject’s right eye precedence. Setting to [Left Eye Priority] gives the subject’s left eye precedence.

The main subject can be selected for tracking with the joystick or touch panel.

Setting the AF area to [Whole Area] AF enables main subject tracking by pressing the joystick in when the camera detects the target subject set in [Subject to Detect]. The joystick can also be pressed left or right to track specific subjects if multiple subjects are detected. Subjects other than those targeted for detection can also be tracked by tapping them. Additionally, regardless of the configured AF area, any preferred subject can be tracked by tapping it or pressing the joystick after using it to move the marker, once the camera is set to tracking selection mode by pressing the assignable button assigned to tracking.

Enables touch-based tracking of any subject regardless of the configured AF area.

Enables main subjects targeted for AF to be switched with the focusing ring, when Continuous AF is enabled and this function is set to [On (Tracking Frame)] in the menu. As the focusing ring is turned, based on the focus position, an orange tracking frame is displayed on a potential subject that users can switch to, and when manual focusing stops, the potential subject by the tracking frame is tracked as the main subject. Whether or not to display tracking frames for potential subjects can be set from the menu. Without a subject in focus, no tracking frame is displayed, and the camera does not switch subjects after manual focusing. Disabling the function in the menu disables this tracking after focusing.

Exposure Control

Manual: Manual setting using shutter, iris, ISO/Gain, and ND filter.
Push Auto Iris*: While the Push Auto Iris button is pressed, the aperture is controlled to achieve proper exposure. If deviation from the proper exposure occurs, it takes control again.
Auto Iris*: Constantly adjusts automatically for proper exposure using iris.
Auto ISO/Gain*: Constantly adjusts automatically for proper exposure using ISO/Gain.
Auto Shutter*: Constantly adjusts automatically for proper exposure using Shutter.
Other:

• AE Response can be changed in the menu.
• Auto ISO/Gain can be used in combination with Auto Iris or Push Auto Iris.

Standard (center-weighted metering), Spotlight, Backlight

*If [EOS Standard] or [EOS Neutral] is selected in [CP File Selection], the setting value will be grayed out and cannot be selected as photometry is performed in the same way as the EOS R series. Editing the CP File (Gamma adjustment, registering another LUT as a Look File), makes it selectable.

AE shift is available (±8 levels relative to center). Levels (EV values) are indicated numerically.

Shutter

Electronic shutter

1/16000*1*2 –30 sec., bulb

* 1 Up to 1/8000 sec. when set to HDR mode, focus bracketing, or same exposure for new aperture (ISO speed/Shutter speed, Shutter speed).

*2 1/10000 and 1/12800 sec. can also be selected.

Not provided

Custom Picture
