PowerLite L690SE 6,000-Lumen Short Throw 3LCD Laser Projector with 4K Enhancement
PowerLite L690SE 6,000-Lumen Short Throw 3LCD Laser Projector with 4K Enhancement
PowerLite L690SE 6,000-Lumen Short Throw 3LCD Laser Projector with 4K Enhancement
PowerLite L690SE 6,000-Lumen Short Throw 3LCD Laser Projector with 4K Enhancement
PowerLite L690SE 6,000-Lumen Short Throw 3LCD Laser Projector with 4K Enhancement
PowerLite L690SE 6,000-Lumen Short Throw 3LCD Laser Projector with 4K Enhancement
No Reviews Q & A
Write your Review
  • Webcode: 488182 • Mfr: V11HB36020
Product Highlights
  • 4K (WUXGA) Max. Resolution
  • Up To 1.07 Billion Colours
  • Up to 5,000,000:1 Contrast Ratio
  • PC / Mac Compatibility
  • 2x HDMI Out / HDBaseT / Mini Stereo / USB Connector Type-A / USB Connector Type-B / RS-232c / Wired LAN / RJ45 Connection
  • 100-240 VAC Power Source
Epson PowerLite L690SE 6,000-Lumen Short Throw 3LCD Laser Projector with 4K Enhancement Epson PowerLite L690SE 6,000-Lumen S...
$7,491.00 Add to Cart
Add to Wishlist
Find it for less? Let us know.
Web Availability: Special Order
This product will be Special Ordered just for you from the manufacturer. We do not stock this item due to its uniqueness or import schedule. Special Order items are Final Sale, see our Return Policy for details.
Vistek Locations
  • Toronto Special Order
  • Ottawa Special Order
  • Mississauga Special Order
  • Calgary Special Order
  • Edmonton Special Order
Please call and verify availability at the store as stock changes daily.
Lease this for: $264.31 Learn More

Overview

PowerLite L690SE 6,000-Lumen Short Throw 3LCD Laser Projector

This incredibly compact projector delivers larger-than-life images with a short 0.5 – 0.7 throw ratio.

Experience the extraordinary versatility and performance of our bright and compact PowerLite L-Series. Expanding on the possibilities of this powerful projector lineup, the PowerLite L690SE features a short 0.5 – 0.7 throw ratio and a large display up to 500". With wide vertical and horizontal lens shifts and 1.4x optical zoom, this flexible projector is ideal for a variety of applications, such as floor and rear projection, golf simulation, museum exhibitions and more. Deliver vivid images in rooms with high-ambient light with 6,000 lumens of equal colour and white brightness. Plus, enjoy a sharp, detailed picture thanks to 4K Enhancement Technology that displays double HD resolution on-screen.

Key Features:

  • 6,000 lumens colour/white brightness
  • WUXGA with 4K Enhancement for clear, detailed images
  • 0.5 – 0.7 throw ratio and 1.4x optical zoom
  • Display up to 500" diagonal in 16:10, plus ultra wide 16:6 and 21:9
  • Lightweight, compact design allows for easy installation

Simple to install, the PowerLite L690SE is easy to operate from start to finish. Built-in NFC functionality, wide lens shift, 360-degree mounting, geometric correction tools and more allow for simple, seamless integration. Created with convenience in mind, the projector features an up to 30,000-hour virtually maintenance-free laser light source and air filter in Extended Mode. In addition, simplify complex multi-projector applications with the optional attachable PixAlign camera. Epson’s PowerLite L-Series offers a range of solutions to meet virtually any application. This lineup also features ultra bright short throw options, including the PowerLite L790SE, which provides a wider 0.8 – 1.36 throw ratio.

What's Included

PowerLite L690SE Projector
Power Cable
Projector Remote Control With Batteries
Quick Setup Sheet
Cable Cover
Quick Setup Poster

Reviews

Product Specifications

PowerLite L690E 3LCD Laser Projector
General Projection System: RGB liquid crystal shutter projection system
Projection Method: Front/rear/ceiling mount
LCD Size: 0.67" (C2 Fine)
Driving Method: Poly-Silicon TFT Active Matrix
Pixel Number: 2,304,000 dots (1920 x 1200) x 3
Native Resolution: WUXGA with 4K Enhancement1 (1920 x 1200 x 2)
Resolution On-Screen: WUXGA with 4K Enhancement1 / 4.6 million pixels
Resize: 640 x 480, 800 x 600, 1280 x 1024, 1400 x 1050
Aspect Ratio: Supports 4:3, 16:10, 16:9*, 16:6*, 21:9* * With vertical image shift control within letterbox area.
Pixel Arrangement: Cross stripe
Color Brightness: Color light output: 6,000 lumens
White Brightness: White light output: 6,000 lumens
Contrast Ratio: Up to 5,000,000:1
Brightness Uniformity (Typical): 88%
Color Reproduction: Up to 1.07 billion colors
Size (Projected Distance): 100" – 500"
Projected Distance: 80" screen 1.38 m
Lens Shift: Vertical: ±50%; Horizontal: ±20%
Keystone Correction: Vertical: ±30 degrees; Horizontal: ±30 degrees
Light Source: Laser Diode
Light Source Life: Normal: 20,000 hours; Quiet: 20,000 hours; Extended: 30,000 hours
Projection Lens Type: Optical Zoom (manual)/Focus (manual)/Corner focus (manual)
F-Number: 1.8 – 2.0
Focal Length: 7.54 mm – 10.55 mm
Zoom Ratio: 1.0 – 1.4x (optical)
Throw Rate Range: 0.5 – 0.7 (optical)
Lens Cover: Lens cap (without string
Other Features Operating Temperature: 32 ˚F to 113 ˚F (0 ˚C to 45 ˚C)
Power Supply Voltage: 100 V – 240 V ± 10%, 50/60 Hz AC
Auto Power On: Signal Detection on HDMI/Plug-In Detection (HDMI, USB, BNC) Sleep Mode: Yes (with timer)
HDMI CEC Control: Yes
Power Consumption: 432 W (Normal Mode) 313 W (Quiet and Extended) 2.4 W (Standby comm on) 0.3 W (Standby comm off)
Fan Noise: 36 dB (Normal Mode); max. 26 dB (ECO Mode)
Security: Security cable hole, Kensington lock provision
A/V Mute: Yes
Speaker(s): N/A
Split Screen: Yes (up to 2 screens)
Content Playback: Yes
Quick Corner: Yes
Arc Correction: Yes
Edge Blending: Yes
Interfaces HDMI (HDCP 2.3) x 2 HDMI Out x 1 HDBaseT x 1 Variable Audio Out: Mini Stereo x 1 USB Connector Type-A x 1 USB Connector Type-B x 1 Serial: RS-232c x 1 Wired LAN RJ45 x 1
Other Features Screen Sharing Yes Corner Wall Yes Curved Surface Yes Camera Yes
Effective Scanning Frequency Range Pixel Clock 25.1 MHz to 594 MHz Horizontal 26 kHz to 135 kHz Vertical 23.98/24/25/29.97/30/50/59.94/60 Hz
Dimensions Excluding Feet 17.32" x 11.97" x 4.80" Including Feet 17.32" x 14.25" x 5.94" Weight 20.5 lb
Network and Remote Control Features Power, source search selection, A/V Mute, number input, menu, esc, select, Freeze, ID, Customize, E-Zoom, mute, volume, playback control and pointer functions Operating Angle Rear: Right/Left: -55 to +55 degrees; Upper/ Lower: +75 to +15 degrees; Front: Right/Left: -30 to +30 degrees; Upper/Lower: 0 to +60 degrees Operating Distance 26 ft (8 m) Network Control PJLink, Creston Integrated partner, Crestron Connected V2 with XiO Cloud, Extron IP link, Extron XTP, AMX, Control
Eco Features RoHS compliant End-of-life options available9 Epson America, Inc. is a SmartWay Transport Partner10 Design and Manufacturing centers utilize 100% renewable electricity Dynamic Contrast (ECO) Mode reduces power consumption by 36%
